的主要用途是什么与介简/Brief Introduction：

超声波焊接机组为10-20ml服用液液體罐装研发线中的一般环保机器设备。是由洗瓶、吹干三合一机和罐装粘口三合一机所分解成，能系统自动实现服用液瓶的洗瓶、吹干、罐装和粘口等运作，是服用液研发批发厂家更非常完美的搭配环保机器设备，压根契合GMP标准。It’s a major equipment in production line for oral filling, it main used in filling, capping placing and sealing of 10-20ml bottles. Tracking filling, cap automatically conveying by electromagnetic oscillator, automatic sealing , no bottle no filling. Filling and sealing integrated in one machine, advanced design, compact structure and completely comply with requirement of GMP

特征/Characteristic：

◆装量小于，制止渗漏。灌装设备要求高。High filling accuracy.◆调频无级调压，出产流速可以调节，可选择择差异的出产流速。Frequency control, production speed is adjustable, you can choose a different production rate.◆大部分电组件均选用国外高知名度茶叶品牌。All electrical components are imported famous brands.◆会自动展示筛选能力。Automatically countting function.◆调节分为澳大利亚三凌PLC，抗串扰，工作的稳定的。Controlled by Mitsubishi PLC◆性平稳，清洁清洁便捷。Stable performance, easy maintenance.◆服务器内心用SUS304不锈冷库保温隔热板的表层钢板网作、与原辅材料接处部位用316L冷库保温隔热板的表层。服务器完完全全按GMP规定制定。Outer material is 304 stainless steel, and the material of filling part is 316L stainless steel. The machine is completely designed according to GMP requirements.

工艺性能指标/technical parameters：

可用规格为/Bottle size	10-20ml
生产方式工作能力/Capacity	60-90瓶/小时/60-90bottles/min
烘干处理室温/Dryer tempreture	100-300°
中水回用河水量/Water wastage	0.5m3/h
活性炭过滤水耗量/Purifying water consumption	0.3m3/h
装量误差/Filling precision	≤1%
24v电源/Voltage	380V/50Hz
输出/Power	33KW
产生线总长/Dimension	3500×1500×1600mm
